Conceptual illustration of motor magnetic components around a central shaft and stator windings – NEOLUNE MAGNETS.

Custom magnet assemblies.

Magnetic components for motor, robotics and automation projects.

From magnetic circuit design and simulation to component assembly, we work to your drawing, target field and installation requirements.

Discuss Your Project

Why work with NEOLUNE MAGNETS

±0.05 mm
3C & robot-joint assembly dimensions, subject to the agreed design
Prototypes from 1 set
Start with a single assembly before scaling up
5–8 working days
Typical samples from mature drawings; timing depends on design, tooling and quantity. Timing starts after drawing confirmation and receipt of sample payment.
Design to assembly
Magnetic circuit simulation and component assembly in one place

Applications

Swipe to explore all 7 applications

Conceptual illustration of magnetic components in a robotic joint servo motor – NEOLUNE MAGNETS.

Robotics

Suitable for compact robot joints requiring smooth motion and precise, contactless position feedback.

  • Joint servo motors
  • Magnetic couplings
  • Magnetic bearings
  • Magnetic position sensors
Conceptual illustration of motor magnetic components in an electric vehicle drive – NEOLUNE MAGNETS.

New energy vehicles

Suitable for lightweight, efficient vehicle drives with responsive steering and precise thermal management.

  • Traction motors (PMSM)
  • EPS motors
  • Coolant pumps & A/C compressors
  • Brake & position sensors
Conceptual illustration of motor magnetic components in a multirotor UAV drive – NEOLUNE MAGNETS.

Aerospace

Suitable for lightweight UAV drives and compact, responsive flight-control actuators.

  • Aero-engine actuators
  • Satellite attitude control
  • UAV motors
  • Flight-control servo motors

Not seeing your application?

Send your drawing, target field and operating conditions. We review custom assemblies from a single prototype set.

Share your project

Magnetic components

Compact 3C magnetic components for electronic equipment and robot joints – NEOLUNE MAGNETS.

3C Magnetic Components

Compact arrays for 3C equipment and robot joints.

Array layout, magnet grade and coating are configured for the application.

  • ±0.05 mm achievable dimensions for 3C and robot-joint assemblies, subject to the agreed design
  • Sorting, positioning, bonding and curing
View details
Segmented laminated magnets for motor magnetic circuits – NEOLUNE MAGNETS.

Laminated Magnets

Insulated magnet segments for motor designs.

Segmentation and insulation are reviewed for the motor design.

  • Arc, block and sector forms
  • Segment insulation and epoxy coating options
View details
Cylindrical motor magnetic components for rotor integration – NEOLUNE MAGNETS.

Motor Magnetic Components

Magnetic components for rotary and linear motor designs.

Dimensions, magnetic layout and installation requirements are reviewed for your motor design.

Motor component types

  • Linear Motor Components
  • Stator & Rotor Components
  • Surface-mounted Rotor Assemblies
  • Inner-rotor (Radial) Permanent-magnet Bearings
View details
Circular potted magnetic components for drawing-based equipment integration – NEOLUNE MAGNETS.

Potted Magnetic Components

Potted magnetic components developed around the project requirements.

Share your drawing and operating conditions to discuss materials, component design and acceptance requirements.

View details
Linear Halbach assemblies for motor magnetic circuits – NEOLUNE MAGNETS.

Halbach Assemblies

Ring and linear structures for a defined working field.

Ring and linear magnetic layouts are designed around the required working field and installation space.

  • Magnetic circuit design and fixture-assisted assembly
  • NdFeB and SmCo options to suit the application
View details
Flanged rectangular magnetic component for climbing-robot integration – NEOLUNE MAGNETS.

Other Projects

Other custom magnets and assemblies for project-specific needs.

Share your application, drawing and expected quantity so we can review the component requirements.

View details
Compare all families

Engineering and assembly.

Two rectangular plates with rows of mounted magnets – NEOLUNE MAGNETS.
  1. Review

    Drawing, target field, installation space and operating conditions.

  2. Design

    Magnetic circuit simulation, material and magnetisation choices.

  3. Assemble

    Magnet sorting, positioning fixtures, bonding and curing.

  4. Deliver

    Finished assemblies, with acceptance checks agreed for the project.

Discuss your custom assembly

Explore engineering and assembly

Quality checks

Dimensions & fit
Component geometry and installation interfaces.
Magnetic field
Working-field mapping and magnetic characteristics.
Surface & coating
Visual condition and the specified finish.
Operating conditions
Temperature and demagnetisation requirements discussed for the application.

±0.05 mm — Achievable overall dimensional accuracy for 3C and robot-joint assemblies, subject to the agreed design.

Explore quality checks

About NEOLUNE MAGNETS

NEOLUNE MAGNETS designs and manufactures 3C magnetic components, laminated magnets, motor magnetic components, potted magnetic components and Halbach assemblies for custom projects.

We combine magnetic circuit design and simulation with component assembly. Share your drawing and operating requirements to discuss materials, installation and production needs.

Read about NEOLUNE MAGNETS

NEOLUNE MAGNETS building entrance and signage for the custom magnetic components business.
NEOLUNE MAGNETS · premises exterior

Working with NEOLUNE

What is needed for a custom assembly?

A drawing or dimensional sketch, application, target magnetic field, installation space, operating conditions and expected quantity help us review the project. If some details are still being developed, share the requirements available so far.

How are materials selected?

We review magnet grade, magnetic circuit, target field, operating temperature and coating together. The choice depends on the component design and working conditions.

Can you make a prototype or a small quantity?

We can make prototypes from a single set. Production minimum order quantities are confirmed for each component specification.

What are the typical lead times?

Mature drawings typically require 5–8 working days. Timing starts after drawing confirmation and receipt of sample payment. A new design with simulation and tooling preparation typically requires 7–15 working days; production typically takes 15–30 working days. Timing is confirmed according to the design, tooling and order quantity.

Are magnets magnetised before or after assembly?

Magnets can be magnetised before or after assembly. We choose the sequence to suit the component size, structure and batch quantity, and plan sorting, positioning, bonding and curing accordingly.

Which inspection reports can be provided?

We can provide batch magnetic-field, dimensional and coating reports. Inspection items, coverage, frequency and report contents are agreed for your component and project.
